Positive Displacement Screw Air Compressor Low Oil Carryover 2-3 Ppm
  • Positive Displacement Screw Air Compressor Low Oil Carryover 2-3 Ppm

Positive Displacement Screw Air Compressor Low Oil Carryover 2-3 Ppm

Place of Origin GERMAN
Brand Name Shanghai Rotorcomp
Certification ISO.TUV,CE,GS
Model Number LGFD-45
Product Details
Product Name:
Screw Air Compressor
Capacity(m3/min):
10 Bar 6.3
Power(kw):
45
In/outlet:
G1-1/4
Noise:
75 DB
Dimension:
1440×1006×1296 MM
Weight:
1400 KG
Feature:
Sand Blasting
High Light:

industrial screw compressor

,

screw drive air compressor

Payment & Shipping Terms
Minimum Order Quantity
negotiate
Price
negotiate
Packaging Details
Plywood case for export package
Delivery Time
5-15 Working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100-2000sets/Month
Product Description

Positive Displacement Screw Air Compressor Low Oil Carryover 2-3 Ppm

Screw Air Compressor Applications

rotary-screw compressor is a type of gas compressor that uses a rotary-type positive-displacement mechanism. They are commonly used to replace piston compressors where large volumes of high-pressure air are needed. Such as:

  1. Sand blasting
  2. General works air
  3. Simple spray painting
  4. Pneumatic tools
  5. Dental laboratories
  6. Medical equipment
  7. food industry
  8. Pharmaceuticals industry


About US

Shanghai Rotorcomp air compressor is an economic air compressor package, with the benefit of a heavy duty working design, low maintenance cost and internal components that are easy exchangeable. LGFD model is flexible for air cooled and water cooled industrial applications.
This series comes in a belt driven motor type (7.5 – 75kw) and a direct driven model (18.5 – 355kw), with working pressures from 7.5 to 13 bar(g), and with Free Air Delivery from 1.2 – 62 m3/min.

Features of Screw Air Compressor

  1. Compact and Simple Design
  2. Microprocessor Control Panel
  3. 2 in 1 Intake Valve Design with Check Valve
  4. Superior Larger 5 : 6 Profile Airend Design
  5. 3 Stage Oil Separation and Low Oil Carryover (2-3 ppm)
  6. Larger Cooler for High Ambient Temperature Area Operation
  7. IP55 High Efficiency Main Motor
  8. 1 : 1 Motor Belt/Direct Couple Airend Design
  9. VSD Inverter Control Standard Configuration Option

Our compressors bring you outstanding performance, flexible operation and the highest productivity, while minimizing the total cost of ownership. Built to perform even in the harshest environments, our products keep your production running smoothly.
Offering best-in-class performance and total reliability, our products answer your advanced needs.
Industry-leading Free Air Delivery.
The lowest power consumption and noise emission in the industry.
Excellent-quality.
Easy monitoring and maintenance.

Parameter of Screw Air Compressor



Model Capacity(m3/min)* Power(kw) In/outlet Noise Dimension Weight
8bar 10bar 13bar 15bar Motor Motor(Fan) dB(A)** L×W×H in mm kg
LGFD-7.5 1.2 1.04 0.9 0.8 7.5 0.09 G1 69 900×750×900 250
LGFD-15 2.4 2.15 1.84 1.66 15 0.18 G1 70 950×800×1290 480
LGFD-18.5 3 2.9 2.52 2.02 18.5 0.37 G1 71 1250×960×1300 730
LGFD-22 3.51 3.16 2.71 2.45 22 0.37 G1 71 1250×960×1300 750
LGFD-30 4.88 4.32 3.64 3.25 30 0.75 G1-1/4 71 1440×1006×1296 1200
LGFD-37 5.83 5.21 4.44 4.01 37 0.75 G1-1/4 73 1440×1006×1296 1350
LGFD-55 9.32 8.33 7.05 6.31 55 1.1 G2 75 1600×1200×1650 1600
LGFD-75 12.31 11.13 9.61 8.74 75 1.1 G2 75 1600×1200×1650 1750
LGFD-90 16.45 14.26 11.72 10.8 90 2.2 G2 75 2000×1580×1790 2600
LGFD-132 20.26 17.48 14.25 13.05 110 2.2 G2 78 2500×1700×1900 3000
LGFD-180 23.08 20.54 17.65 16.05 132 2.2 G2 78 2500×1700×1900 3150
Note:
1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail;
2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail;
  1. Frequency converters (optional).
  2. 2 years warranty, 5 years warranty for air end



To achieve sustainable development

Extra low noise emission

Develop by Jersey North America Development Center--- low noise SKY air end
Heavy machinery design
Direct driven and no gear noise
Low-speed centrifugal fan and inverter oil cooling fan
Equipped with air intake Muffler
World class lowest noise emission

Energy conservation

Each set of air compressor meets national energy conservation standards
Rotorcomp high efficient air end made in Germany
High efficient motor engine
Direct drive and no gear energy saving loss
High efficient centrifugal fan
Inverter oil cooling fan and suction cooling down
Germany suction valve
