5.5kw - 160kw Air End Screw Compressor Intelligent Control System
  • 5.5kw - 160kw Air End Screw Compressor Intelligent Control System
  • 5.5kw - 160kw Air End Screw Compressor Intelligent Control System
  • 5.5kw - 160kw Air End Screw Compressor Intelligent Control System
  • 5.5kw - 160kw Air End Screw Compressor Intelligent Control System

5.5kw - 160kw Air End Screw Compressor Intelligent Control System

Place of Origin Germany
Brand Name Shanghai Rotorcomp
Certification ISO.TUV,CE,GS
Model Number EVO screw compressor
Product Details
Warranty:
5 Years
Air End:
Made In Germany
Advanced Design:
Design In Germany
Cooling System:
Enlarged Air Cooling System Than 20-25% With Better Performance
Motor:
IP55 In IEC3 Super High Efficient Motor
Driving System:
Protection System
Contractor:
Schneider Brand
Controller:
Touchable Colorful Controller As Option
Maintenance:
Simple&advanced Design For Low Maintenance Cost
High Light:

Intelligent Control System Rotary Air Compressor

,

Screw Air End Compressor 5.5kw

,

Intelligent Air End Screw Compressor

Payment & Shipping Terms
Minimum Order Quantity
Min.:1set
Price
Negotiable
Packaging Details
Exported Wooden Package
Delivery Time
15-20 working days
Payment Terms
Western Union, T/T, L/C, D/P, D/A
Supply Ability
3,000 sets/per month
Product Description

5.5kw-200kw screw air compressor in unique design TUV certificates 5 year warranty



Advantages of LGFD High-end Series Screw Compressor:

1. World-leading Made in Germany Rotorcomp screw air end
2. 5 years warranty
3. Extraordinary cooling system design
4. Intelligent control system
5. higher efficient energy-saving motor in IE3 CE&MEPS
6. Unique driving guard system
7. ISO,TUV,GA,SGS certificates



Advantages of our new EVO air screw compressor technology

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 0

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 1

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 2





All of our EVO air screw compressors have special Drives and electrics system that is almost loss-free power transmission guarantees reliable, high-performance compressor operation. The regular maintenance requirement is reduced to lubrication of the motor.



All the electronic components are brand products of leading manufacturers. rives and electrics. The Air end of our EVO rotary screw compressor-made in Germany. The centrepiece of the compressor is the air end, which is constructed and manufactured with the most modern production methods in Germany. The optimal air end for your compressor can be used on a modulating basis. In frequency-controlled units, where the operating pressure changes, adjustments can also be made on the frequency controller to optimally adjust the speed of the compressor to the compressor performance.

We design the new Oil separation system for our EVO air screw compressor that Compressors up to 132 kW are equipped with external separators that can be changed in a simple spin-off/spin-on process. Larger units have an internal separator cartridge. Due to the excellent separation efficiency of the system as a whole, the compressors can be used in the pressure range of 5.0 to 15.0 bar. Special pressures on request.

And the Oil circuit of our EVO rotary screw compressor is the amount of oil in the units is determined in such a way as to extend the oil change intervals (depending on ambient conditions).An oil level sensor is integrated as standard and is read by the controller. All the units in this series have a horizontal oil separation vessel in which the oil is separated from the compressed air highly efficiently at low speeds.







Model Capacity(m3/min)* Power(kw) In/outlet Noise Dimension Weight
8bar 10bar 13bar 15bar Motor Motor(Fan) dB(A)** L×W×H in mm kg
LGFD-5.5 0.87 0.75 0.61 0.53 5.5 0.09 G1 69 900×750×900 245
LGFD-7.5 1.2 1.04 0.9 0.8 7.5 0.09 G1 69 900×750×900 250
LGFD-11 1.79 1.58 1.32 1.17 11 0.18 G1 70 950×800×1290 370
LGFD-15 2.4 2.15 1.84 1.66 15 0.18 G1 70 950×800×1290 480
LGFD-18.5 3 2.9 2.52 2.02 18.5 0.37 G1 71 1250×960×1300 730
LGFD-22 3.51 3.16 2.71 2.45 22 0.37 G1 71 1250×960×1300 750
LGFD-30 4.88 4.32 3.64 3.25 30 0.75 G1-1/4 71 1440×1006×1296 1200
LGFD-37 5.83 5.21 4.44 4.01 37 0.75 G1-1/4 73 1440×1006×1296 1350
LGFD-45 7.08 6.3 5.43 4.94 45 1.1 G1-1/4 75 1440×1006×1296 1400
LGFD-55 9.32 8.33 7.05 6.31 55 1.1 G2 75 1600×1200×1650 1600
LGFD-75 12.31 11.13 9.61 8.74 75 1.1 G2 75 1600×1200×1650 1750
LGFD-90 16.45 14.26 11.72 10.8 90 2.2 G2 75 2000×1580×1790 2600
LGFD-132 20.26 17.48 14.25 13.05 110 2.2 G2 78 2500×1700×1900 3000
LGFD-180 23.08 20.54 17.65 16.05 132 2.2 G2 78 2500×1700×1900 3150
Note:
1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail;
2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail;

3. Frequency converters (optional).

4. 1 years warranty, 5 years warranty for air end





5.5kw - 160kw Air End Screw Compressor Intelligent Control System 3

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 4



5.5kw - 160kw Air End Screw Compressor Intelligent Control System 5

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 6

5.5kw - 160kw Air End Screw Compressor Intelligent Control System 7
