Touch Screen Small Rotary Screw Compressor , Oil Free Screw Compressor
  • Touch Screen Small Rotary Screw Compressor  , Oil Free Screw Compressor

Touch Screen Small Rotary Screw Compressor , Oil Free Screw Compressor

Place of Origin Germany
Brand Name Shanghai Rotorcomp
Certification ISO.TUV,CE,GS
Model Number Small Rotary Screw Compressor
Product Details
Name:
Small Rotary Screw Compressor
Air End:
Touch Screen
Design:
Unique Design In Germany
Dimension:
Smaller&Integrated
High Light:

vsd air compressor

,

oil injected screw compressor

Payment & Shipping Terms
Minimum Order Quantity
Min.:1set
Price
Negotiable
Packaging Details
Exported Wooden Package
Delivery Time
5-15 working days
Payment Terms
Western Union, T/T, L/C, D/P, D/A
Supply Ability
3,000 sets/per month
Product Description

Touch Screen Small Rotary Screw Compressor , Oil Free Screw Compressor



Extra low noise emission



Develop by Jersey North America Development Center--- low noise SKY air end

Heavy machinery design

Direct driven and no gear noise

Low-speed centrifugal fan and inverter oil cooling fan

Equipped with air intake Muffler

World class lowest noise emission



Advantages of NK High-end Series Screw Compressor:


Hot sale! Oil Lubricated Rotary Air Screw Compressor
1. World-leading ROTORCOMP integrated air end Made in Germany
2. 5 years warranty
3. Unique Extraordinary cooling system design
4. Economic running costs
5. ISO, TUV, CE, SGS certificates

All Shanghai Rotorcomp NK high-end air screw compressors assembled with unique series of EVO®-NK compact units that are oil-injected screw compressor modules integrated the main parts of a compressor system.
This solution is the best possible way to build a reliable, compact and cost-efficient complete compressor package with ultimate efficiency, low noise and the highest quality standards.






Why use NK high-end integrated screw compressor?

Economic running costs


Capacity,0-100% adjustment When the gas consumption is reduced, the capacity decreases, following motor current is also reduced, our NK high-end air screw compressor is running without capacity, if this status keeps for a long time, compressor automatically shut down. While air consumption increases, compressors recovers. The energy-saving effect is optimal.

Good environmental adaptability


Extraordinary cooling system design, especially for the high-temperature, high humidity environment. Excellent vibration isolation and noise reduction measures, so that the installation of our NK high-end air screw compressor no need for a dedicated basis, only to leave a minimum ventilation and maintenance space, you can settle your compressor.





Mode

Capacity m3/min

Power/
(KW)

Weight/
Kg

Noise/
dB(A)

Dimension/
L×W×H(mm)

7 bar

8 bar

10 bar

13 bar

15 bar

LGFD7.5 *

1.30

1.20

1.00

0.75

0.60

7.5

290

65±3

900×650×1290

LGFD11 *

1.70

1.60

1.50

1.15

0.90

11

350

65±3

900×650×1290

LGFD15 *

2.25

2.05

1.85

1.50

1.20

15

360

67±3

900×650×1290

LGFD18.5*

3.10

2.90

2.55

2.10

1.80

18.5

565

70±3

790×1360×1220

LGFD22*

3.60

3.40

3.00

2.50

2.30

22

600

70±3

790×1360×1220

LGFD30*

5.20

4.90

4.40

3.70

3.00

30

810

72±3

930×1660×1530

LGFD37*

6.30

6.00

5.40

4.70

4.10

37

830

72±3

930×1660×1530



Note:

1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail;

2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail;

3. Frequency converters (optional).
4. 1 years warranty, 5 years warranty for air end
