Tank Mounted 25 Hp Screw Air Compressor , Diesel Air Compressor Filters Combined 18.5Kw

Place of Origin GERMAN
Brand Name SHANGHAI ROTOROCMP
Certification ISO,CE,TUV
Model Number LGSD18.5
Minimum Order Quantity 1
Price negotiable
Packaging Details Plywood case for export package
Delivery Time 5-15 Working days
Supply Ability 100-2000sets/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Brand New Typ Screw
Power Source AC Power Lubrication Style Lubricated
Mute Yes Voltage 220-440v/50-60hz
Warranty 1 Year Rated Power 18.5KW/25HP
Dimension 1500×1000×1750mm Weight 810Kg
Noise 73dB
High Light

industrial screw compressor

,

screw drive air compressor

Leave a Message
Product Description

Tank Mounted 18.5Kw 25Hp screw air compressor air dryer,filters combined

Compact, heavy duty, quiet and highly reliable belt &direct driven rotary screw compressors series, to satisfy all the requirements.



The LGSD series comprises a comprehensive range of premium quality rotary screw air compressors from 4 kW to 15 kW. Each model is constructed to the highest standard using the best quality components in order to ensure a long life and total reliability.

The design of the LGSD series benefits from years of experience in the production of innovative high quality air compressors where attention to detail and quality are at the highest level.



The advanced controllers fitted to the LGSD range have been specifically developed to guarantee optimum monitoring and regulation of the compressor’s operation, allowing flexibility and full programming of the complete compressed air station for maximum efficiency and safety.



ELECTRONIC CONTROLLER

(installed on models from 11 to 18.5 kW)

Controller with multi-function and multi-language backlight LCD graphic display, the menu is drop down type. In the main screen are displayed:

- Working pressure (offload/load);

- Oil temperature;

- Compressor status (stand-by, offload, load);

- Fan status (off/on);

- Date and time;

Hours remaining before maintenance



Tank Mounted 25 Hp Screw Air Compressor , Diesel Air Compressor Filters Combined 18.5Kw 0



OUR OWN INTAKE REGULATOR

Normally open electro- pneumatic system: adjusts the compressor operation to guarantee minimum pressure when idle running and maximum saving upon start-up.

All this translatesinto an optimal energy cost/air delivery ratio.

   Tank Mounted 25 Hp Screw Air Compressor , Diesel Air Compressor Filters Combined 18.5Kw 1



THERMOSTATIC VALVE

The thermostatic valve regulates the oil temperature, preventing the formationof condensate inside the oil-separator vessel.

Tank Mounted 25 Hp Screw Air Compressor , Diesel Air Compressor Filters Combined 18.5Kw 2





EVO® – Screw air ends
Reliable and versatile
Our oil-injected screw air ends create the heart of your compressor system. Used with our wide range of components, you can build the perfect compressor package with ultimate efficiency, low noise, at the highest quality standards.


Advantages of our new EVO® technology Ultimate efficiency and reduced noise through
New ROLLING PROFILE® – ultimate efficiency with
reduced noise

Long life cycle due to increased bearing dimensions
and wear-free ROLLING PROFILE®

Wide operating pressure range from 5 to 15 barg
High quality manufacturing and assembling –
“Made in Germany”
Quality assurance – bench test of every air end
before leaving our factory

Easy application selection with our new
ROTORCOMP® SIZING AIR software

Highest flexibility for your package design
• Suitable for all types of drive driving motors
• Drive options: Belt drive, direct drive, internal


Tank Mounted 25 Hp Screw Air Compressor , Diesel Air Compressor Filters Combined 18.5Kw 3






Model



Tank



Power



Air delivered

Max. Pressure Sound level



Connection



Net Weights

Net Dimensions L x W x H
  lt kW HP m3/min. m3/h CFM bar p.s.i. dB(A) G Kg (cm)
LGSD 18.5-08-500 500 18.5 25 2.85 171 102 8 116 73 1-1/2" 810 150 x 100 x 175
Note:
1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail;
2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail;

3. Frequency converters (optional).
4. 1 years warranty, 5 years warranty for air end


Screw air compressor main spare parts configuration:

Item Parts Brand
1 Air end Rotorcomp(Germany)
2 Intake Valve Rotorcomp(Germany)
3 Solenoid Valve Danfoss(Danmark)
4

Temperature

sensor

Danfoss(Danmark)
5 Pressure sensor

Huba original (from

Switzerland)

6 Motor Hebei
8

Thermostat

Valve

Rotorcomp
9 PLC PLOT
10

Minimal

Pressure Valve

rotorcomp
11 Air filter element Mann(Germany)
12 Oil filter element Mann(Germany)
13

Oil separator

element

Mann(Germany)
14 Bearing

Sweden SKF (Life 60000

hours)
