Airend Design 2 Stage Air Compressor , Waterproof Quiet Air Compressor
| Place of Origin | GERMAN |
|---|---|
| Brand Name | Shanghai Rotorcomp |
| Certification | ISO.TUV,CE,GS |
| Model Number | LGFD-75 |
| Minimum Order Quantity | negotiate |
| Price | negotiate |
| Packaging Details | Plywood case for export package |
| Delivery Time | 5-15 Working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 100-2000sets/Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 2 Stage Air Compressor | Capacity(m3/min) | 8 Bar 12.31 |
|---|---|---|---|
| Power(kw) | 75 | In/outlet | G2 |
| Noise | 75dB | Dimension | 1600×1200×1650 MM |
| Weight | 1750 KG | Feature | Airend Design |
| High Light | industrial screw compressor,screw drive air compressor |
||
Product Description
Airend Design 2 Stage Air Compressor , Waterproof Quiet Air Compressor
2 Stage Air Compressor
Historical well-known manufacturer producing quality screw compressor,oil free compressor,high pressure compressor in ISO,TUV,CE certificates with good price, 5 years warranty, patented unique design, more energy-saving , reliable compressor system for all kinds of projects.
Advantages of our new EVO technology
1. New ROLLING PROFILE– ultimate efficiency with
reduced noise
2. Long life cycle due to increased bearing dimensions
and wear-free ROLLING PROFILE
3. Wide operating pressure range from 5 to 15 barg
Air end –
4. “Made in Germany”
5. Quality assurance – bench test of every air end
before leaving our factory
6. Easy application selection with our new
ROTORCOMP-SIZING AIR software
7. Highest flexibility for your package design
• Suitable for all types of drive driving motors
• Drive options: Belt drive, direct drive, internal
gear drive
• Base and face-flange mounting
Features of 2 Stage Air Compressor
- Compact and Simple Design
- Microprocessor Control Panel
- 2 in 1 Intake Valve Design with Check Valve
- Superior Larger 5 : 6 Profile Airend Design
- 3 Stage Oil Separation and Low Oil Carryover (2-3 ppm)
- Larger Cooler for High Ambient Temperature Area Operation
- IP55 High Efficiency Main Motor
- 1 : 1 Motor Belt/Direct Couple Airend Design
- VSD Inverter Control Standard Configuration Option
To achieve sustainable development
Extra low noise emission
Develop by Jersey North America Development Center--- low noise SKY air end
Heavy machinery design
Direct driven and no gear noise
Low-speed centrifugal fan and inverter oil cooling fan
Equipped with air intake Muffler
World class lowest noise emission
Energy conservation
Each set of air compressor meets national energy conservation standards
Rotorcomp high efficient air end made in Germany
High efficient motor engine
Inverter oil cooling fan and suction cooling down
Germany suction valve
High reliability
World class R&D team---provide the powerful safeguard to product quality
"Rotorcomp" rotor line, cylinder bearing or taper-roller bearing integrative design, bearing lifespan >>100,000 hours
Direct drive, large rotor and slow rotation speed
Five years warranty for main machine, two years warranty for motor and radiator
Patent air valve and patent cooler
Coolant and three filters imported from Germany
First class production process and inspection equipment, realize the designer’s philosophy perfectly
Parameter of
| Model | Capacity(m3/min)* | Power(kw) | In/outlet | Noise | Dimension | Weight | |||||
| 8bar | 10bar | 13bar | 15bar | Motor | Motor(Fan) | dB(A)** | L×W×H in mm | kg | |||
| LGFD-5.5 | 0.87 | 0.75 | 0.61 | 0.53 | 5.5 | 0.09 | G1 | 69 | 900×750×900 | 245 | |
| LGFD-7.5 | 1.2 | 1.04 | 0.9 | 0.8 | 7.5 | 0.09 | G1 | 69 | 900×750×900 | 250 | |
| LGFD-11 | 1.79 | 1.58 | 1.32 | 1.17 | 11 | 0.18 | G1 | 70 | 950×800×1290 | 370 | |
| LGFD-15 | 2.4 | 2.15 | 1.84 | 1.66 | 15 | 0.18 | G1 | 70 | 950×800×1290 | 480 | |
| LGFD-18.5 | 3 | 2.9 | 2.52 | 2.02 | 18.5 | 0.37 | G1 | 71 | 1250×960×1300 | 730 | |
| LGFD-22 | 3.51 | 3.16 | 2.71 | 2.45 | 22 | 0.37 | G1 | 71 | 1250×960×1300 | 750 | |
| LGFD-30 | 4.88 | 4.32 | 3.64 | 3.25 | 30 | 0.75 | G1-1/4 | 71 | 1440×1006×1296 | 1200 | |
| LGFD-37 | 5.83 | 5.21 | 4.44 | 4.01 | 37 | 0.75 | G1-1/4 | 73 | 1440×1006×1296 | 1350 | |
| LGFD-45 | 7.08 | 6.3 | 5.43 | 4.94 | 45 | 1.1 | G1-1/4 | 75 | 1440×1006×1296 | 1400 | |
| LGFD-55 | 9.32 | 8.33 | 7.05 | 6.31 | 55 | 1.1 | G2 | 75 | 1600×1200×1650 | 1600 | |
| LGFD-90 | 16.45 | 14.26 | 11.72 | 10.8 | 90 | 2.2 | G2 | 75 | 2000×1580×1790 | 2600 | |
| LGFD-132 | 20.26 | 17.48 | 14.25 | 13.05 | 110 | 2.2 | G2 | 78 | 2500×1700×1900 | 3000 | |
| LGFD-180 | 23.08 | 20.54 | 17.65 | 16.05 | 132 | 2.2 | G2 | 78 | 2500×1700×1900 | 3150 | |
| Note: | |||||||||||
| 1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail; | |||||||||||
| 2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail; | |||||||||||
| |||||||||||
