Industrial Oil Free Scroll Air Compressor / Laboratory Air Compressor 33Kw/44Hp
Oil Free Scroll Air Compressor Advantages
1. Easy to move out the elements
Good substitute of small oil free screw compressor with lower cost of maintenance, and more simple structure with energy-saving performance in food&beverage,pharmaceutical,automobile,medical&chemical,prescion and electronic industry.
Advanced design for air cooling system better performance than other compressor 15-20%
2. Space saving and environmental protection:
The products has compact structure, smaller size, with less occupation of the land, lower noise and vibration, it can be installed in any place where you need it, even in the production area can be used.
Why to choose Oil Free Scroll Air Compressor ?
1. More simple structure,less wearing part
2. lower maintenance cost and cheaper price
3. lower noise and less vibration
4. Medical equipment(medical,dentists gas source as oxygen
5. Gas separation system equipment(adsorption&membrance separation of oxygen and nitrogen)
Advanced design for air cooling system better performance than other compressor 15-20%
German Design Air End with Low Noise Running
|
Model |
Capacity(m3/min) |
Power(kw) |
In/outlet |
Noise |
Dimension |
Weight |
|
8bar |
Moto |
dB(A) |
L×W×H in mm |
kg |
||
|
|
|
|
|
|
|
|
|
RC-D30/08-S1 |
3.0 |
27.5 |
1-1/2 |
75 |
1250×1360×1560 |
1010 |
|
Note: |
|
1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail; |
|
2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail; |
|
3. Frequency converters (optional). 4. 1 year warranty, 2 years warranty for air end |
Multimachine intelligent composite control-mode
•Multi-machine intelligent control can adjust to the required air consumption and automatically start/stop, avoiding unnecessary energy costs.
•If using less air, reduce the highest pressure automatically and decreasing running pcs to realize energy save running.
