Silent 10 Hp Rotary Screw Air Compressor Belt - Driven Transmission
  • Silent 10 Hp Rotary Screw Air Compressor Belt - Driven Transmission

Silent 10 Hp Rotary Screw Air Compressor Belt - Driven Transmission

Place of Origin GERMAN
Brand Name Shanghai Rotorcomp
Certification ISO.TUV,CE,GS
Model Number LGSD 7.5-08-300
Product Details
Product Name:
Rotary Screw Type Compressor
Tank:
300IT
Power:
7.5KW 10 HP
Air Delivered:
1.25m3/min.
Max.:
8Bar
Sound:
60dB(A)
Connection:
3/4"G
Net Dimensions L X W X H:
120 X 65 X 154cm
High Light:

industrial screw compressor

,

screw drive air compressor

Payment & Shipping Terms
Minimum Order Quantity
negotiate
Price
negotiate
Packaging Details
Plywood case for export package
Delivery Time
5-15 Working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100-2000sets/Month
Product Description

Silent 10 Hp Rotary Screw Air Compressor Belt - Driven Transmission



10 Hp Rotary Screw Air Compressor Features



  1. High efficiency cooling
  2. Longer usage life
  3. Big volume air tank
  4. Easy operation
  5. High performance
  6. Oil-free, belt driven, piston type
  7. Conpetitive Price with First Class Quality



10 Hp Rotary Screw Air Compressor Introduction



The LGSD series comprises a comprehensive range of premium quality rotary screw air compressors from 4 kW to 15 kW. Each model is constructed to the highest standard using the best quality components in order to ensure a long life and total reliability.

The design of the LGSD series benefits from years of experience in the production of innovative high quality air compressors where attention to detail and quality are at the highest level.



LGSD Series 10 Hp Rotary Screw Air Compressor  Parameters





Model

Tank Power Air delivered Max. Pressure Sound level Connection Net Weights Net Dimensions L x W x H
lt kW HP m3/min. m3/h CFM bar p.s.i. dB(A) G Kg (cm)
LGSD 4.0-08-300 300 4 5.5 0.58 34.8 20.5 8 116 60 1/2" 246 120 x 65 x 154
LGSD 4.0-10-300 300 4 5.5 0.49 29.1 17.1 10 145 60 1/2" 246 120 x 65 x 154
LGSD 7.5-08-300 300 7.5 10 1.25 75 44.1 8 116 66 3/4" 385 120 x 65 x 154
LGSD 7.5-10-300 300 7.5 10 1.00 60 35.3 10 145 69 3/4" 385 120 x 65 x 154
LGSD 7.5-13-300 300 7.5 10 0.75 45 26.5 13 188 69 3/4" 385 120 x 65 x 154
LGSD 11-08-300 300 11 15 1.65 99 58.2 8 116 69 3/4" 469 155 x 70 x 153
LGSD 11-10-300 300 11 15 1.50 90 53 10 145 69 3/4" 469 155 x 70 x 153
LGSD 11-13-300 300 11 15 1.15 69 40.6 13 188 69 3/4" 469 155 x 70 x 153
LGSD 15-08-300 300 15 20 2.15 129 75.9 8 116 70 3/4" 573 155 x 70 x 153
LGSD 15-10-300 300 15 20 1.85 111 65.3 10 145 70 3/4" 573 155 x 70 x 153
LGSD 15-13-300 300 15 20 1.55 93 54.7 13 188 70 3/4" 573 155 x 70 x 153
